CJ1W-ID212 | OMRON CJ-series Input Units CJ1W-ID212

OMRON CJ1W-ID212 Manual And Instructions
CJ1W-ID212 datasheetPDF datasheet
CJ1W-ID212 HardwarePROGRAMMING MANUAL
CJ1W-ID212 I/O Wiring Diagram

OMRON CJ1W-ID212 Product information and technical parameters:
Brand: OMRON
Name: CJ-series Input Units
Model: CJ1W-ID212
Unit type: CJ1 Basic I/O Units.
Product name: DC Input Units.
Specifications: I/O points, 16 inputs(High speed);
Input voltage and current: 24 VDC, 7 mA;
Commons, 16 points, 1 common; External connection,
Removable terminal block; No. of words allocated, 1 word.
Current consumption: 5V, 0.13A; 24V, --.
Standards: N, L, CE.
A Wide Range of Basic Input,
Units for High Speed Input and,
Different Applications.
Receive ON/OFF signals from external,
devices into the PLC System to update,
I/O memory in the CPU Unit.
New high-speed input models CJ1W-ID212 and,
CJ1W-ID233 are now available. These units can,
help to increase system throughput.

Name: Loop-control CPU Unit.
I/O bits: 960 bits.
Program capacity: 10K steps.
DM words: 32K words.
EM words: 32K words × 1 bank E0_00000 to E0_32767.
Versatile Machine Control with the,
Highest Performance Standards in the Industry. Name: Loop-control CPU Unit.
I/O bits: 1,280 bits.
Program capacity: 60K steps OMRON CJ1W-ID212.
DM words: 32K words.
EM words: 32K words × 3 banks E0_00000 to E2_32767 CJ1W-ID212
Versatile Machine Control with the,
Highest Performance Standards in the Industry. Unit type: CJ1 CPU Bus Units.
Product Name: Position Control,
Units with EtherCAT interface.
Specifications: Control output interface,
Control commands executed by,
EtherCAT communications.
Positioning functions: Memory operation,
Direct operation by ladder programming;
No OMRON CJ1W-ID212. of axes: 4 axes.
No. of unit numbers allocated: 1.
Current consumption : 5V, 0.46A; 24V,--.
Standards: UC1, CE.
Preeminent control performance and,
easy operation feature of EtherCAT,
improve the production efficiency.
The EtherCAT communications with,
100Mbps baud rate enables fast,
and accurate position control OMRON CJ1W-ID212.
A wide range of position control,
functions are available with,
this position control unit.
Unit type: CJ1 CPU Bus Unit.
Product Name: Controller Link Unit.
Specifications:Communications cable,
Wired shielded wisted-pair cable ;
Communications type,
Data links and message service;
Duplex support, No;
Max. Units mountable per CPU Unit, 8;
No. of unit numbers allocated: 1.
Current consumption : 5V, 0.35A; 24V,--.
Standards: UC1, N, L, CE.
New Controller Link Units,
Now with 4,000 Send Words.
The Controller Link is an FA,
network that can send and receive,
large amounts of data easily,
and at high speed CJ1W-ID212.
The Controller Link supports data,
links that enable sharing,
data between PLCs and computers,
and a message service that enables,
sending and receiving data whenever required.
Systtems can be flexibly built by using Repeater,
Units to enable T-branches, long-distance wiring,
and converting part of the network to optical cable CJ1W-ID212.
