C200HX-CPU44-ZE | OMRON CPU Unit C200HX-CPU44-ZE

C200HX-CPU44-ZE Introduce | C200HX-CPU44-ZE Catalog / Manual / Instructions / Software download

OMRON C200HX-CPU44-ZE Manual And Instructions
C200HX-CPU44-ZE OPERATION MANUAL

OMRON C200HX-CPU44-ZE Product information and technical parameters：
Brand: OMRON
Name: CPU Unit
Model: C200HX-CPU44-ZE
UM: 31.2K words.
DM: 6K words.
EM: 6Kx3 banks(18K) words.
Instruction processing time (basic instructions): 0.1 µ.s min.
No. of I/O points: 880 points.
Max. no.of con-necting Expansion I/O Racks: 2 Racks.
Max. no. of connecting High-density I/O Units(i.e., Group-2): Unavailable.
Max. no. of con-necting Special I/O Units: 10.
RS-232C: NO.

Cover for 10-pin terminal block.
Terminal cover for 8-point or 5-point I/O Units.Model: C200H-MR832.
Description: RAM, 8K words, capacitor back-up.no clock.C200H Accessory Interface Unit C200H-IP006C200H Accessory Programming Console Adapter C200H-BP001.8 pts, No-voltage contact. NPN.Power supply voltage: DC100V OMRON C200HX-CPU44-ZE.
Note: operation with output contacts.
Power supply unit.
The power supply of the CPU rack is supplied by the power supply unit C200HX-CPU44-ZE
The following power units are available for selection.
C200HW-PA204 (voltage: AC100-120V/AC200-240V)
C200HW-PA204S (voltage: AC100-120V/AC200-240V)
C200HW-PA204R (voltage: AC100-120V/AC200-240V)
C200HW-PD024 (voltage: DC24V)
In the past, PC connected to a measurement equipment or components must be given to the ASCII unit or BASIC unit to write a communication program OMRON C200HX-CPU44-ZE.
Now, PC C200HX/HG/HE is installed on the communication protocol macro function,
Can be configured to these communications procedures through the PMCR instruction to the ladder program,
With this function system can be easily connected with a wide range of components.Name: Connector OMRON C200HX-CPU44-ZE.
Model: C200H-CE002.8 pts, 1 A, 120 VAC.Capacity: 16K word.
Access time: 150ns.
When using SYSMAC-CPT, can not be written in EPROM.
To write a program to the EPROM, use the standard PROM writer.
Before the EPPROM memory card into the CPU, to connect the EPROM to the EPROM memory card.
If you remove the EPROM memory card from the CPU,
Will not lose its data.Name: Wired Master.
Model: C200H-RM201.Name: Connector.
Model: C200H-CE001.Write voltage: 12.5V.
Access time: 150ns.Model: C200H-AD003.
Input points: 8.
Voltage input: 1 to 5 V, 0 to 10 V, or –10 to 10 V.
Current input:: 4 to 20 mA C200HX-CPU44-ZE. No. of I/O slots: 8 slots.ASCII Unit
This program runs independently from the ladder-diagram program in the PLC.

Name: ASCII Module.
Model: C200H-ASC31.
Communications port>Port 1: RS-232C(peripheral device connec-tion)) C200HX-CPU44-ZE.
Communications port>Port 2: RS-232C(peripheral device connec-tiC200H Power Supply Aux PS for SLK11 C200H-APS03.
Required when supplying backup power.
