>> H3DS-SL | OMRON Solid-state Multi-functional Timer H3DS-SL
H3DS-SL | OMRON Solid-state Multi-functional Timer H3DS-SL
OMRON H3DS-SL Manual And Instructions
H3DS-SL datasheetPDF datasheet
OMRON H3DS-SL Product information and technical parameters：
Brand: OMRON
Name: Solid-state Multi-functional Timer
Model: H3DS-SL
Supply voltage: 24 to 230 VAC (50/60Hz)/24 to 48 VDC.
Control output: Contact output: SPDT (time-limit output SPDT).
Input type: No-input available.
Operating mode(see note): Eight multi-modes: Four multi-modes: A, B2, E, J.
Model: Screw terminal type.
Eight operating modes (H3DS-M) and four operating modes,
(H3DS-S) cover a wide range of applications.
A wide time setting range of 0.10 s to 120 h.
Two LEDs indicate power and relay status respectively.
