>> H3CR-G8L-30 | OMRON Star delta timer H3CR-G8L-30
H3CR-G8L-30 | OMRON Star delta timer H3CR-G8L-30
OMRON H3CR-G8L-30 Manual And Instructions
H3CR-G8L-30 datasheetPDF datasheet
H3CR-G8L-30 INSTRUCTION MANUAL
OMRON H3CR-G8L-30 Product information and technical parameters：
Brand: OMRON
Name: Star delta timer
Model: H3CR-G8L-30
Type: no instantaneous contact.
Terminal configuration type: special terminal configuration.
Pin type: 8 pin.
Action mode / reset mode: time limit action / auto reset.
Output mode: contact output.
Installation method: embedded installation / front mounting.
1 units can be in 0.5 seconds to 120 seconds, select the 4 time range.
Achieved UL, CSA, NK, LR certification, in compliance with EN61812-1.
Conform to the CE mark, CCC.
