>> E5DC-QX2ASM-802 | OMRON Digital Temperature Controller E5DC-QX2ASM-802
E5DC-QX2ASM-802 | OMRON Digital Temperature Controller E5DC-QX2ASM-802
OMRON E5DC-QX2ASM-802 Manual And Instructions
E5DC-QX2ASM-802 datasheetPDF datasheet
OMRON E5DC-QX2ASM-802 Product information and technical parameters：
Brand: OMRON
Name: Digital Temperature Controller
Model: E5DC-QX2ASM-802
Control output: Voltage output.
Auxiliary output: Two.
Communications: RS-485.
Heater burnot: Detection for Single-phase heater.
Event inputs: --.
Power supply voltage: 100 to 240 VAC.
The E5DC-800 Mounts to DIN Track and Is Ideal,
for Connections to HMIs and PLCs.
It provides the Same Easy Operation and,
Advanced Performance as the Rest of the,
E5@C-800 Series.
A slim body at 85 × 22.5 mm (D × W) that fits into narrow control,
panels and mounts to DIN Track.
Removable terminal block for easy replacement to simplify maintenance.
High-speed sampling at 50 ms for applications with high-speed,
temperature increases.
Easy connections to a PLC with programless communications.
Models are available with up to 2 auxiliary outputs and 1 event input to,
complete basic functions.
A white PV display (height: 8.5 mm) is easy to read when setting up,
checking alarms, and making settings in a control panel.
