Brand: OMRON
Name: Multi connection type limit switch
Model: VB-2321
Type: winged.
Drive shaft type: semi cylindrical plug type.
Outlet hole: 4.
Even number: 2.
Rubber material: NBR.
Head and body integration, strength and sealing performance is better, mechanical life is also significantly increased (5 million times).
The most suitable for a variety of machine tools, automatic production line of the order control.
With drain holes, oil and water can be discharged after immersion.
