OMRON SS Series Product information and technical parameters：
Brand: OMRON
Name: Subminiature Basic Switch
Model: SS Series
Subminiature Basic Switch,
Offers High Reliability and,
Security.
The OMRON''s best-selling micro switches of a,
wide variety from 0.1A to 10.1A.
A variety of models are available, with operating,
force ranging from low to high.
Two split springs ensure a high stability and,
durability of 30,000,000 operations.
...More relevant models >>>>
