>> S8T-DCBU-02 | OMRON Buffer Block S8T-DCBU-02
S8T-DCBU-02 | OMRON Buffer Block S8T-DCBU-02
OMRON S8T-DCBU-02 Manual And Instructions
S8T-DCBU-02 datasheetPDF datasheet
S8T-DCBU-02 EtherNet/IP Connection Guide
OMRON S8T-DCBU-02 Product information and technical parameters：
Brand: OMRON
Name: Buffer Block
Model: S8T-DCBU-02
Input voltage: 24 VDC (24 to 28 VDC).
Output voltage(during backup operation): 22.5 V.
Output current: 2.5 A.
Prevents Equipment Stoppage, Data Loss,
and Other Problems Resulting from Momentary.
Power Failures.
Provides a backup time of 500 ms at an output current of 2.5 A.
Can be wired to the 24-V output from the S8VS Supplies.
Connects to an S8TS Power Supply via an S8T-BUS03 Bus Line Connector.
Parallel connections to up to four Blocks can be used to increase,
the backup time and current capacities.
Complies with SEMI F47-0200 standard.
RoHS-compliant.
Ambient operating temperature range of –20 to 60°C.
