>> S8T-DCBU-01 | OMRON DC Backup Block for S8TS S8T-DCBU-01
S8T-DCBU-01 | OMRON DC Backup Block for S8TS S8T-DCBU-01
OMRON S8T-DCBU-01 Manual And Instructions
S8T-DCBU-01 datasheetPDF datasheet
S8T-DCBU-01 EtherNet/IP Connection Guide
OMRON S8T-DCBU-01 Product information and technical parameters：
Brand: OMRON
Name: DC Backup Block for S8TS
Model: S8T-DCBU-01
Input voltage: 24 to 28 VDC.
Output voltage: 24 V.
Output current: 3.7 A/8 A (See note 2.).
DC Backup Block for S8TS Prevents 24-VDC.
Outages Due to Power Interruptions or Failures.
Supplies 24 VDC for a fixed period of time even during.
AC input outages to considerably improve system reliability.
Block Power Supply Basic Block is connected using a Bus Line.
Connector to achieve a simple system configuration.
Notification of alarms is provided by indications on the main unit.
and alarm signal output.
RoHS-Compliant.
