>> S8FS-C03505J | OMRON Switch Mode Power Supply S8FS-C03505J
S8FS-C03505J | OMRON Switch Mode Power Supply S8FS-C03505J
OMRON S8FS-C03505J Manual And Instructions
S8FS-C03505J datasheetPDF datasheet
S8FS-C03505J datasheetPDF datasheet
OMRON S8FS-C03505J Product information and technical parameters：
Brand: OMRON
Name: Switch Mode Power Supply
Model: S8FS-C03505J
Power rating: 35 W.
Input voltage: 100 to 240 VAC (allowable range: 85 to 264 VAC or 120 to 370 VDC*1).
Output voltage: 5 V VDC.
Output current: 7 A.
Built-in fan: None.
Model with terminal block facing forward.
High Reliability at a Reasonable Cost.
Reliable, Basic Power Supplies That,
Contribute to Stable Equipment Operation.
High Reliability: Enhanced abnormal overvoltage,
resistance and lightning surge resistance for stable,
operation even with an unstable input voltage.
Long Life: Japanese 105°C electrolytic capacitors are used,
to achieve stable quality and long life. A reliable 3-year warranty.
Wide Input Ranges: 100 to 120 VAC and 200 to 240 VAC,
Full Lineup: Models are available for the main output,
voltages and capacities used in FA applications.
Global Standards: Conforms to CE (all models),
Approved for UL (all models) and CCC (15 to 150-W models).
Easy mounting to DIN Rails with Mounting Brackets (sold separately).
Refer to Period and Terms of W.
...More relevant models >>>>
