>> S8BA-24D24D360LF | OMRON Uninterruptible Power Supply S8BA-24D24D360LF
S8BA-24D24D360LF | OMRON Uninterruptible Power Supply S8BA-24D24D360LF
OMRON S8BA-24D24D360LF Manual And Instructions
S8BA-24D24D360LF datasheetPDF datasheet
S8BA-24D24D360LF datasheetPDF datasheet
S8BA-24D24D360LF User's Manual
S8BA-24D24D360LF Connection Guide
OMRON S8BA-24D24D360LF Product information and technical parameters：
Brand: OMRON
Name: Uninterruptible Power Supply
Model: S8BA-24D24D360LF
Input voltage: 24 VDC.
Output voltage: 24 VDC.
Output current/capacity: 15 A/360 W.
Compact DC-DC UPS with a DIN rail for,
mounting, best suited for prevention of,
voltage drop and power failure in,
industrial-purpose computers.
(IPC)/controllers.
System reliability greatly improved because.
24VDC power supply is backed up for a certain.
period of time in the event of voltage drop or power failure.
Compactness, weight reduction, and long battery life,
realized thanks to the adoption of a lithium-ion battery.
Push-in terminal block adopted for the power input and,
output I/F.
Shutdown in conjunction with the industrial,
purpose computer (IPC) or controller realized,
by the USB/RS-232C/I/O port installed in the UPS.
