OMRON S82S-7705 Product information and technical parameters：
Brand: OMRON
Name: Switch Mode Power Supply
Model: S82S-7705
Power ratings: 7.5 W.
Output voltage: 5 V.
Output current: 1.5 A.
Miniature DIN Rail Mounting DC-DC Power.
Supplies.
65 mm depth enables mounting onto control panels with.
100 mm depth.
Inputs: 10.2 to 27.6 VDC (DC input).
7.5-W models provide both ±12-V and ±15-V outputs.
A complete lineup with 10 different models.
UL and CSA approved.
RoHS-compliant.
