>> K8DS-PZ1 | OMRON Three-phase Voltage, Asymmetry, and Phase-sequence Phase-loss Relay K8DS-PZ1
K8DS-PZ1 | OMRON Three-phase Voltage, Asymmetry, and Phase-sequence Phase-loss Relay K8DS-PZ1
OMRON K8DS-PZ1 Manual And Instructions
K8DS-PZ1 datasheetPDF datasheet
OMRON K8DS-PZ1 Product information and technical parameters：
Brand: OMRON
Name: Three-phase Voltage, Asymmetry, and Phase-sequence Phase-loss Relay
Model: K8DS-PZ1
Rated input voltage: 3-phase 3-wire mode, 200, 220, 230, or 240 VAC.
Ideal for Monitoring 3-phase Power Supplies.
for Industrial Facilities and Equipment.
Greater resistance to inverter noise.
Monitor undervoltages, overvoltages, voltage asymmetry, phase,
sequence, and phase loss in three-phase three-wire circuits with one unit.
One SPDT output relay, 5 A at 250 VAC (resistive load).
World-wide power specifications supported by one unit.
(Set with a rotary switch.).
Relay status can be monitored using LED indicator.
