OMRON K3HB-PNB-FLK3AT11 AC100-240 Product information and technical parameters：
Brand: OMRON
Name: Time interval table
Model: K3HB-PNB-FLK3AT11 AC100-240
Input type: NPN/ voltage pulse input type.
Event input terminal 5 points (HOLD, RESET) equipped with.
External power supply DC12V80mA.
Note: K3HB-RPB-A, K3HB-RNB-A is not equipped with event input.
Communication: RS-485; NPN open collector (HH, H, PASS, L, LL).
96 (W) * 48 (H * 95mm) depth.
Power supply voltage: AC100 ~ 240V.
Measurement of 2 points through the speed, time, or cycle of the digital time interval table.
Action determine the color, can switch the green / Red 2 kinds of color display.
Measurement of wide range of pulse interval time.
Measuring, calculating and displaying the pulse interval between 2 points.
Range of pulse interval measurement,

Supply voltage: 24, 100 to 120, 200 to 230 VAC; 12, 24, 48, 100 to 110, 125 VDC.
Time-limit contact: 4PDT.
Short-time range model (0.1 s to 10 min).
Miniature Timer with Multiple Time Ranges,
and Multiple Operating Modes.
UL listed when used with a Push-In Plus Terminal Block Socket.
Conforms to CSA, CE Marking, LR, and CCC OMRON K3HB-PNB-FLK3AT11 AC100-240.
Black design with power supply terminals on top and contact output,
terminals on bottom K3HB-PNB-FLK3AT11 AC100-240
Standard multiple operating modes and multiple time ranges.
Pin configuration compatible with MY Power Relay.
Minimizes stock. Count input: PNP/NPN universal DC voltage input(4.5 to 30 VDC).
Max. counting speed: 30 Hz ←→ 1 kHz(switchable).
Display: 7-segment LCD with backlight OMRON K3HB-PNB-FLK3AT11 AC100-240.
Model: Black body.
Eight-digits, counting range 0 to 99999999.
Dual input speed: 30 Hz ←→ 1 kHz,
(except for AC/DC multivoltage input models). DIN-sized (48 x 48, 45 x 75 mm) Timer with.
Digital Setting and LCD Display.
Dual power supplies for free AC/DC.
Eight operation modes selectable with one unit.
Any desired time can be set digitally within a range from 0.1,
seconds to 9,990 hrs OMRON K3HB-PNB-FLK3AT11 AC100-240.
Four external signal inputs.
ON/OFF indicator for control output and bar indicator for,
remaining time.
Conforms to UL, CSA, and CE marking. Operation system: Time-limit operation, integrating operation.
Resetting system: Power-OFF resetting (excluding -M), external resetting,
manual resetting, automatic resetting.
No. of digits: 4 digits (switch-selectable):
0.01 to 99.99 s, 0.1 to 999.9 s, 1 to 9999 s, 0.1
to 999.9 min, 0.1 to 999.9 hrs, 1 to 9999 hrs,
1 s to 99 min 59 s, 1 min to 99 hrs 59 min.
Backup power supply function for memory protection: Can be,
enabled and disabled with a DIP switch.
DIN-sized (72 x 72 mm) Quartz Timer with,
Multiple Functions.
Wide time range from 1/100 seconds to 9999 hrs.
Built-in power supply incorporated in timer enables direct,
connectioon of sensors and other components K3HB-PNB-FLK3AT11 AC100-240.
Draw-out construction allows maintenance without,
disconnecting the wiring.
Power supply freely selectable within a range of 100 to 240 VAC;
a DC-operated version is also available. K3HB-PNB-FLK3AT11 AC100-240.
Control outputs of both contact type and transistor type,
simultaneously available.
Seven operating modes (N, F, C, R, K, P, and Q) are available.
