>> G3FD-102SN DC5-24 | OMRON Solid state relay G3FD-102SN DC5-24
G3FD-102SN DC5-24 | OMRON Solid state relay G3FD-102SN DC5-24
OMRON G3FD-102SN DC5-24 Manual And Instructions
G3FD-102SN DC5-24 datasheetPDF datasheet
OMRON G3FD-102SN DC5-24 Product information and technical parameters：
Brand: OMRON
Name: Solid state relay
Model: G3FD-102SN DC5-24
Standard certification: No.
Action indicator: there.
Applicable load of output: DC5 2A ~ 110V.
Input rated voltage: DC5 ~ 24V.
Insulation: photo coupler.
Zero trigger function: No.
And the MY type of the same shape of the G3F series of new international standard certification (-VD type).
Achieved UL, CSA, EN (VDE certification) standard certification. (type -VD)
Socket terminal type of same size with MY (2 pole type).
A model with an action indicator to check the status of the input.
