>> E63-WF5C | OMRON Direct Discrimination Unit E63-WF5C
E63-WF5C | OMRON Direct Discrimination Unit E63-WF5C
OMRON E63-WF5C Manual And Instructions
E63-WF5C datasheetPDF datasheet
E63-WF5C INSTRUCTION sheet
OMRON E63-WF5C Product information and technical parameters：
Brand: OMRON
Name: Direct Discrimination Unit
Model: E63-WF5C
Power supply voltage: 12 to 24 VDC.
Output configuration: Open-collector output.
Detects the Rotary Encoder Direction.
Input phase difference signal from the Encoder to detect the,
direction of rotation.
High-speed response at 120 kHz.
Mounts to DIN Track. Thin design enables superb mounting efficiency.
Front-panel switch enables reversing phase Z logic.
Enables connecting either voltage outputs or open-collector outputs.
