OMRON E5EC-QR2DDM-800 Product information and technical parameters：
Brand: OMRON
Name: Simple digital temperature controller
Model: E5EC-QR2DDM-800
Type: plug - in.
Size: 48 x 96mm.
Control output 1: voltage output.
Control output 2: relay output.
Auxiliary output: 2 points.
Communication: -.
Heater disconnection: -.
Event input: -.
Power supply voltage: AC/DC24V.
Using large font PV display (white), improve visibility.
Selection, setting and operation more simple and more group of input / output,
Functional performance is stronger, the function is more perfect and more extensive range of applications.
E5EC-800 white LCD-PV display height is about 18mm,
The E5AC-800 white LCD-PV display height is about 25mm improved visibility.
The main body is short, the thickness is only 60mm.
50ms high speed sampling period.
A new type of proportional control allows you to control the valve.
