>> DRT2-OD08CL-1 | OMRON Environment-resistive Terminals with Transistors DRT2-OD08CL-1
DRT2-OD08CL-1 | OMRON Environment-resistive Terminals with Transistors DRT2-OD08CL-1
OMRON DRT2-OD08CL-1 Manual And Instructions
DRT2-OD08CL-1 datasheetPDF datasheet
DRT2-OD08CL-1 OPERATION MANUAL
DRT2-OD08CL-1 INSTRUCTION Manual
OMRON DRT2-OD08CL-1 Product information and technical parameters：
Brand: OMRON
Name: Environment-resistive Terminals with Transistors
Model: DRT2-OD08CL-1
Specifications: Outputs, PNP (+ common), 8 points.
I/O connections: Sensor I/O connector.
Rated internal circuit power supply voltage:
Supplied from the communications. connector.
Rated I/O power supply voltage: 24 VDC.
Remote I/O Terminals with High.
Degree of Environmental Resistance.
(IP67) in Product Lineup Including.
Economical Input, Output, and Mixed I/O Models.
Common Smart Slave functionality provides strong support for equipment,
operation status monitoring and effective maintenance.
High degree of environmental resistance with dust-proof and drip-proof,
construction. (IP67)
Models with one connector for two outputs are available to make easier,
connection with hydraulic valve devices.
(Models with 16 outputs and models with 16 mixed I/O)
...More relevant models >>>>
