OMRON D5B-1023 Product information and technical parameters：
Brand: OMRON
Name: Mechanical Touch Switch
Model: D5B-1023
Type: M10.
Actuator: Cone-shaped actuator.
Cable length: 3 m.
Detects Objects in Multiple Directions,
with High Sensitivity, Ideal for Robotics,
Slow-action switching mechanism used.
Gold-plated contact with coil spring capable of switching,
micro current/voltage load while providing high contact reliability.
Inputs directly to microcomputers and programmable controllers.
Three sizes (M10, M8, and M5) and three types of compact actuators.
Easy panel mounting.
