>> D4N-1D20R | OMRON Pull-reset Safety Limit Switch D4N-1D20R
D4N-1D20R | OMRON Pull-reset Safety Limit Switch D4N-1D20R
OMRON D4N-1D20R Manual And Instructions
D4N-1D20R datasheetPDF datasheet
D4N-1D20R INSTRUCTION sheet
OMRON D4N-1D20R Product information and technical parameters：
Brand: OMRON
Name: Pull-reset Safety Limit Switch
Model: D4N-1D20R
Actuator: Roller lever (resin lever, resin roller).
Conduit size: 1-conduit; Pg13.5.
Built-in switch mechanism: 3NC (Slow-action).
A Series of Pull-reset Models Now.
Available.
Lineup includes three contact models with 2NC/1NO and 3NC,
contact forms in addition to the previous contact forms 1NC/1NO and 2NC.
M12-connector models are available, saving on labor and,
simplifying replacement.
Standardized gold-clad contacts provide high contact reliability.
Can be used with both standard loads and microloads.
Conforms to EN115, EN81-1 and EN81-2.
Certified standards: UL, EN (TÜV), and CCC.
...More relevant models >>>>
