>> D4B-4170N | OMRON Safety Limit Switch D4B-4170N
D4B-4170N | OMRON Safety Limit Switch D4B-4170N
OMRON D4B-4170N Manual And Instructions
D4B-4170N datasheetPDF datasheet
D4B-4170N INSTRUCTION sheet
OMRON D4B-4170N Product information and technical parameters：
Brand: OMRON
Name: Safety Limit Switch
Model: D4B-4170N
Actuator: Plunger.
Conduit openings: M20.
1NC/1NO (Snap-action).
Robust safety limit switch with metal housing.
Slow-action and snap-action contact with,
certified direct opening operation certification.
Direct opening mechanism (NC contacts only) added to,
enable opening contacts when faults occur, such as fused contacts.
Safety of lever settings ensured using a mechanism that,
engages a gear between the operating position indicator plate and the lever.
Equipped with a mechanism that indicates the applicable,
operating zone, as well as push-button switching to control left and right motion.
Head seal structure strengthened to improve seal properties.
(TÜV: IEC IP67, UL: NEMA 3, 4, 4X, 6P, and 13).
Wide standard operating temperature range: –40 to 80°C (standard type).
Certified standards: UL, CSA, EN (TÜV), and CCC.
