CRT1-TS04P | OMRON Analog I/O Slave Units CRT1-TS04P

CRT1-TS04P Introduce | CRT1-TS04P Catalog / Manual / Instructions / Software download

OMRON CRT1-TS04P Manual And Instructions
CRT1-TS04P datasheetPDF datasheet

OMRON CRT1-TS04P Product information and technical parameters：
Brand: OMRON
Name: Analog I/O Slave Units
Model: CRT1-TS04P
Name: Temperature Input Units.
Specifications: Platinum-resistance,
thermometer input; 4 inputs;
PT100 (-200 to 850°C),
PT100 (-200 to 2000°C).
Standards: CE, UC, UC1, N .
"Easy" and "Flexible" system expansion,
with linked CC-Link and CompoNet.
Branching is easily made with CompoNet.
Wiring material cost can be reduced.
Bit-level I/O distribution reduces,
wiring in the system.
A wide variety of CompoNet Slave Units,
contribute to system size reduction.
Seven-segment Display on the Gateway Unit,
helps to detect errors on site.
The Participation Flags and Communications,
Error Flags can be checked at the Host,
Controller to detect the location and,
content of the error.

Specifications: I/O; PNP (input: - common,
output: + common); 8 inputs/8 outputs.
I/O connections: Sensor connector.
Rated internal circuit power supply voltage:
Supplied from the communications connector.
Rated I/O power supply voltage:
Supplied from external source for outputs.
Includes Sensor Connector That Conforms to,
Industry Standards And Can Be Used to Connect OMRON CRT1-TS04P.
Sensors with Pre-wired Cables without Using,
Special Tools CRT1-TS04P
Equipped with the standard Smart Slave,
functions that provide powerful.
preventative maintenance and,
troubleshooting capabilities.
Digital I/O Terminal compatible with,
industry-standard sensor connectors.
Connect sensors easily without special tools OMRON CRT1-TS04P.
Reduce time required for wiring.
Load short-circuit detection. Input capacity: 16 points.
Internal I/O common: NPN.
ON voltage: 15 VDC min.
(between each input terminal and the V terminal)
OFF voltage: 5 VDC max.
(between each input terminal and the V terminal)
OFF current: 1.0 mA max.
Input current: 6.0 mA max./input (at 24-VDC),
3.0 mA min./input (at 17-VDC).
ON delay: 0.1 ms max OMRON CRT1-TS04P.
OFF delay: 0.2 ms max.
Input filter value: Without filter, 0.5 ms, 1 ms,
2 ms, 4 ms, 8 ms, 16 ms, 32 ms. (Default setting: 1 ms)
Number of circuits per common: 8 points/common.
Input indicators: LED display (yellow).
Isolation method: Photocoupler isolation.
I/O power supply method: Supply by I/O power supply.
Input device supply current: 100 mA/point.
Unit power supply current consumption: 90 mA max.
(for 20.4 to 26.4-VDC power supply voltage)
I/O power supply current consumption: 5 mA max.
(for 20.4 to 26.4-VDC power supply voltage)
Weight: 370 g max.
Expansion functions: No.
Short-circuit protection function: No.
A common terminal is provided for each contact.
It eliminate the needs for relay terminal blocks.
It is unnecessary to share the common terminal,
among multtiple contacts CRT1-TS04P.
Easy-to-find wiring locations.
Detachable screw terminal block facilitates the maintenance.
Input response time can be switched for high-speed processing.
Selectable node address setting methods: setting with rotary,

switch and with tool software CRT1-TS04P.
When setting the nodes with rotary switch, setting is easy and,
node identification becomes possible for maintenance.
