CJ1H-CPU66H | OMRON Programmable Controllers CJ1H-CPU66H

Unit classification: CJ1 CPU Bus Units.
Product name: Motion Control Unit with,
MECHA TROLINK-II interface.
Specifications: Control modes : Position,
speed, or torque control via MECHATROLINK-II,
Control axes : 32 axes max. (30 physical axes,
2 virtua axes).
Internal programming language: Special motion contro
language
No OMRON CJ1H-CPU66H. of unit numbers allocated: 1.
Current consumption: 5V, 0 CJ1H-CPU66H60A; 24V, --.
Standards: UC1, CE.
Improve Equipment Design Efficiency,
and Shorten Tact Time.
Control Servos for up to 16 axes in,
a motion network with one Position,
Control Unit that supports MECHATROLINK-II.
MECHATROLINK-II is a registered trademark,
of the MECHATROLINK Members Association. Product name: CJ1M CPU Units; Without built-in I/O OMRON CJ1H-CPU66H.
Specifications: I/O capacity/Mountable Units Expansion Racks),
160 points/10 Units (No Expansion Rack); Program capacity,
5K steps; Data memory capacity, 32K words(DM: 32K words, EM: None);
LD nstruction execution time, 0.1 μs.
Current consumption: 5v, 0.58A (Seenote 1.) ; 24V,--.
Standards: UC1, N, L, CE.
Versatile Machine Control with the,
Highest Performance Standards in the Industry OMRON CJ1H-CPU66H. Unit classification: CJ1 Special I/O Units.
Product name: Process Input Units,
(Isolated type Units with Universal Inputs).
Input points: 4 inputs.
Signal range selection:
Set separately for each input.
Signal range:Fully universal
inputs: Pt100, JPt100, Pt1000, K,
J, T, L, R, S, B, 4 to 20 mA, 0 to 20 mA,
1 to 5 V, 0 to 5 V, 0 to 10 V.
Conversion speed (resolution): Conversion,
speed: 250 ms/4 inputs.
Accuracy at ambient temperature of 25°C:
Accuracy: Platinum resistance thermometer,
input: ±0.3% of PV or ±0.8°C, whichever,
is larger) ±1 digit max. Thermocouple input:
(±0.3% of PV or ±1.5°C, whichever is larger),
±1 digit max. *1 Voltage or current input:
±0.3% of F.S. ±1 digit max.
External connection: Removable terminal block.
No. of unit numbers allocatedd: 1 CJ1H-CPU66H.
Current consumption: 5V, 0.32A; 24V, --.
Standards: UC1, L, CE.
A Single Unit Handling All Types of Inputs,
such as Temperature Sensor Inputs and,
Analog Signal Inputs (e.g., 4 to 20 mA or 1 to 5V).
A Unit supports four inpuut channels,
each of which can be set to a
platinum resistance thermometer, thermocouple,
and DC signal (current, voltage) CJ1H-CPU66H.
All inputs are isolated.
